Term: retriggerable interval relay with control signal off
Synonym1: fleeting off delay relay
[Preferred]
Synonym2:
Synonym3:
Symbol:
Definition: time relay in which the output immediately changes to the operate condition and the time delay starts when applying the power supply and removing the control signal; the output switches to the release condition after the setting time has elapsed (see Figure 13)

X

NOTE – Cycling the control signal during the time delay will retrigger the time delay.


Publication date:2010-10
